What Is Transformer Architecture?
Transformer Architecture is a neural network architecture that uses attention mechanisms to process and understand relationships within input data. The easiest way to understand it is to think about reading a sentence.
Consider: “The child put the toy in the box because it was broken.”
To understand what “it” refers to, you need to look at the other words in the sentence. A Transformer does something similar. Its attention mechanism helps the model decide which parts of the input are relevant when interpreting a particular token.
This is one of the biggest differences between Transformers and older sequence-based models. Rather than depending entirely on processing one item after another, Transformers can examine relationships across the input more directly.
Origin of Transformer Architecture
The Transformer was introduced in 2017 through the paper Attention Is All You Need, published by researchers from Google and the University of Toronto.
Before Transformers became popular, RNNs and LSTMs were widely used for language and other sequence-related tasks. These models worked well in many situations, but processing long sequences sequentially could make training slower and make it harder to maintain useful information across long distances.
The Transformer introduced an architecture centred around attention. It could process tokens in parallel during training, making it much easier to take advantage of modern computing hardware.
That change helped open the door to today's large-scale language models.
Why Is Transformer Architecture Important in Machine Learning?
Transformers have several qualities that make them useful for machine learning:
- They can identify relationships between different parts of an input.
- They can process many tokens in parallel during training.
- They work well with large datasets.
- They can be scaled to create very large models.
- The same basic idea can be adapted to different types of data.
- They can be pretrained and later adapted for specific tasks.
These characteristics have made Transformers useful far beyond their original NLP applications.
A Simple Analogy
Imagine you're reading a news article. When you come across a particular sentence, you don't completely ignore everything that came before it. You use the surrounding words and earlier information to understand its meaning.
A Transformer works in a somewhat similar way. Its attention mechanism helps it decide which pieces of information deserve more attention when processing a particular token.
Transformer Architecture in Machine Learning
In machine learning, Transformers are used to learn patterns and relationships within data.
They are particularly useful when the relationship between different elements matters. In text, those elements are usually tokens. In an image, they can be image patches. In other applications, they may represent audio segments or other pieces of information.
One major advantage is parallel processing. During training, a Transformer does not have to wait for every token to be processed before working on the next one. This makes large-scale training much more practical.
Transformer-based models are now used for:
- Text classification
- Machine translation
- Question answering
- Text summarisation
- Text generation
- Information extraction
- Image classification
- Speech and audio processing
- Multimodal AI
Transformer Architecture Diagram
The diagram below gives a quick view of how information moves through a Transformer, from the initial input to the final output.It also shows how the encoder and decoder fit into the overall architecture.
A simplified view of the original Transformer can be shown as:
Here is what each stage does:
Stage |
Purpose |
| Input | Receives the original sequence |
| Embedding | Converts tokens into numerical vectors |
| Positional Encoding | Adds information about token position |
| Encoder | Builds a contextual representation of the input |
| Decoder | Uses the representation to produce output |
| Output | Produces the final prediction or sequence |
One important point: not every Transformer today contains both an encoder and a decoder. Some models use only the encoder, while others use only the decoder.
Also Read: Top 10 Natural Language Processing Examples in Real Life
Key Components of Transformer Architecture
A Transformer is built from several interconnected components, with each one handling a specific part of the data-processing process. Together, these components help the model understand context, identify relationships between tokens, and produce meaningful outputs.
Component |
What It Does |
| Tokenisation | Breaks text into smaller tokens |
| Embedding | Converts tokens into numerical vectors |
| Positional Encoding | Provides information about token order |
| Self-Attention | Helps the model identify relationships between tokens |
| Multi-Head Attention | Allows the model to examine different relationships at the same time |
| Feed-Forward Network | Further processes the representations |
| Residual Connection | Helps information move through deeper layers |
| Layer Normalisation | Helps keep training stable |
| Encoder | Processes and represents input information |
| Decoder | Generates output sequences |
These components are arranged into layers, and multiple layers can be stacked to build a larger Transformer model.
Looking to apply generative AI to real business challenges? Explore upGrad’s IIMK AI for Business Professionals Certificate Program and build practical skills to make smarter, AI-driven business decisions.
How Does Transformer Architecture Work?
At a high level, Transformer Architecture follows a series of steps that turn raw input into useful predictions. The model converts the input into numerical representations, adds positional information, identifies important relationships, and then generates an output.
Input Text → Tokenisation → Embeddings → Positional Information → Attention → Feed-Forward Network → Output
Now let's look at what happens at each stage.
Step 1: Tokenisation
A Transformer does not read a sentence in the same way a person does. The input is first broken into tokens.
For example
“Transformers process language.”
Could become:
[Transformers] [process] [language]
The exact tokens depend on the model's tokenisation method. A word can sometimes be split into smaller pieces.
Once the sentence has been converted into tokens, the model can work with them mathematically.
Step 2: Input Embeddings
Tokens are converted into numerical representations called embeddings.
You can think of an embedding as a list of numbers that represents a token in a mathematical space.
For example, Token → Vector representation
The model learns these representations during training. Tokens that appear in related contexts can develop useful relationships in this vector space.
The important pointis that the Transformer cannot work directly with words such as “language” or “computer.” It needs numerical representations.
Step 3: Positional Encoding
There is a small problem with processing tokens in parallel: the model needs to know their order.
Consider these two sentences:
“The dog chased the cat.”
“The cat chased the dog.”
The same words appear, but the meaning is different because their positions have changed.
Positional information gives the model a way to account for token order. The original Transformer used positional encodings, while newer architectures may use other methods for representing position.
Step 4: Self-Attention
This is where things get interesting. Self-attention allows a token to consider other tokens in the same sequence when building its representation.
Take this sentence: “The animal crossed the road because it was tired.”
The model needs to work out what “it” relates to. Self-attention allows it to examine the surrounding context and assign different levels of importance to different tokens.
The mechanism uses three concepts:
- Query (Q): What information is this token looking for?
- Key (K): What information can another token provide?
- Value (V): What information should be passed along?
A simplified form of the attention calculation is:
Attention (Q, K, V) = softmax(QKᵀ / √dₖ)V
The calculation produces attention weights. These weights determine how strongly information from different tokens contributes to the current representation.
Step 5: Multi-Head Attention
One attention operation may capture some relationships, but different relationships can matter at the same time. That's why Transformers use multi-head attention.
Each attention head can learn to focus on different patterns. For instance, one head might learn relationships between a verb and its subject, while another may focus more on references between words.
The outputs from the different heads are then combined.This gives the model a broader view of the input than relying on a single attention calculation.
Step 6: Feed-Forward Neural Network
The attention mechanism's output passes through a feed-forward neural network.
This network applies additional transformations to the representation of each position.
Attention helps the model gather relevant information. The feed-forward layer then processes that information further.
Together, these operations form the basic computational pattern repeated across Transformer layers.
Step 7: Add & Norm
Transformer layers also use residual connections and layer normalisation.
A residual connection takes information from an earlier stage and adds it to the result of a later operation. This gives information a clearer path through the network and helps when many layers are stacked together.
Layer normalisation helps make the training process more stable.
These details may sound small, but they are important when building and training deep Transformer models.
Step 8: Output Generation
What happens at the end depends on the model and the task.
For a text-generation model, the model may predict the next token.
For example,
“The weather today is” → “sunny”
The newly generated token can then be used as part of the context for the next prediction.
For classification tasks, the output might instead be a label or probability.
Also Read: The Evolution of Generative AI From GANs to Transformer Models
Encoder and Decoder in Transformer Architecture
The encoder processes the input and creates a contextual representation. The decoder uses that information to generate the output.
The original Transformer introduced two main parts:
Encoder + Decoder
What Is a Transformer Encoder?
The encoder takes the input sequence and builds a representation that captures information about the tokens and their relationships.
A typical encoder layer contains:
- Multi-head self-attention
- Feed-forward neural network
- Residual connections
- Layer normalisation
The encoder is especially useful when the main goal is to understand the input.
For example, an encoder can help with
- Text classification
- Sentiment analysis
- Information extraction
- Question answering
- Search-related tasks
BERT is a well-known example of an encoder-based Transformer model.
What Is a Transformer Decoder?
The decoder is designed to generate output.
In the original encoder-decoder Transformer, the decoder receives information from the encoder and uses it while generating the output sequence.
A typical decoder includes:
- Masked self-attention
- Cross-attention
- Feed-forward neural network
- Residual connections
- Layer normalisation
Masked self-attention is particularly important for generation. It prevents the model from looking at future tokens that it has not generated yet.
GPT-style models use a decoder-only approach.
Encoder-Decoder Architecture
When both parts are used together, the process can look like:
Input → Encoder → Contextual Representation → Decoder → Output
Machine translation is a classic example.
Suppose the input is an English sentence and the required output is French. The encoder processes the English sentence, while the decoder uses that information to generate the French translation.
This type of architecture is also useful for other sequence-to-sequence tasks.
Also Read: 15+ Top Natural Language Processing Techniques To Learn in 2026
Types of Transformer Architecture
Transformer-based models are commonly grouped into three categories: encoder-only, decoder-only and encoder-decoder.
Encoder-Only Transformers
Encoder-only models use the encoder part of the original Transformer design.
They are generally better suited to understanding and representing input rather than generating long sequences.
Common applications include:
- Text classification
- Sentiment analysis
- Named entity recognition
- Information extraction
- Question answering
Example- BERT
BERT uses Transformer encoders to build contextual representations of language.
Decoder-Only Transformers
Decoder-only models use the decoder side of the Transformer design for autoregressive generation.
The model predicts the next token using the tokens that have already appeared in the sequence.
For example,
“Artificial intelligence is” → “changing”
The process continues until the model produces the required output.
Example: GPT
GPT-style models use decoder-only Transformer architectures and are widely associated with text generation and generative AI.
Encoder-Decoder Transformers
Encoder-decoder models retain both sides of the original Transformer design.
The encoder reads and represents the input. The decoder then uses that information to produce an output.
These models are useful for tasks where one sequence needs to be converted into another.
Example: T5\\
T5 uses an encoder-decoder Transformer architecture and approaches many NLP problems as text-to-text tasks.
Comparison of Transformer Types
Type |
Main Purpose |
Example |
| Encoder-only | Understanding input | BERT |
| Decoder-only | Generating output | GPT |
| Encoder-decoder | Input-to-output transformation | T5 |
Read : Why Is GPT Called Transformer?
Real-World Examples of Transformer Architectur
The Transformer idea has been adapted into many different models. A few well-known examples show how flexible the architecture can be.
BERT
BERT is an encoder-based Transformer model designed mainly for understanding language.
It builds contextual representations of words by considering the surrounding text. This makes it useful for tasks such as classification, information extraction and question answering.
GPT
GPT-style models use a decoder-only Transformer architecture.
They generate text by predicting the next token based on the context available so far. This makes them useful for applications such as chatbots, writing assistants, code generation and other generative AI tasks.
T5
T5 uses both an encoder and decoder.Its approach is to frame many NLP tasks as text-to-text problems. For example, an input can be transformed into a summary, translation or answer.
This makes the same basic architecture useful for several different language tasks.
Vision Transformer (ViT)
Transformers are not limited to text. Vision Transformer, or ViT, applies the same broad attention-based idea to images. Instead of treating an image as one large object, it divides the image into smaller patches.
These patches can be represented as tokens and passed through Transformer layers. The model can then learn relationships between different parts of an image.
Modern Multimodal Models
More recent AI systems can work with multiple types of information.
Depending on the model, this can include:
- Text
- Images
- Audio
- Video
- Transformers are well suited to this direction because the same attention-based principles can be adapted to connect different types of input.
- Also Read: What is NLP Neural Network?
Why Is Transformer Architecture Important for Modern AI?
Transformer Architecture has become a key part of many AI systems because it can handle large amounts of information while capturing relationships between different parts of the input.
Its flexibility has also helped researchers build models for language, images, content generation, and other complex AI tasks.
1. Foundation of Many AI Systems
Many current AI models use Transformer-based designs. The architecture provides a flexible starting point that can be trained on large datasets and adapted to different tasks.
2. Growth of Large Language Models
Transformers made it much more practical to train increasingly large language models.
As researchers increased model size, training data and computing resources, Transformer-based language models became capable of handling increasingly complex language tasks.
Also Read: Natural Language Processing Algorithms
3. Generative AI
Generative AI has benefited significantly from decoder-based Transformers.
A language model can generate an answer, paragraph, code snippet or summary by repeatedly predicting what should come next based on the existing context.
This basic idea powers many text-generation applications.
4. Multimodal Systems
Transformer-based approaches are also being used to connect different forms of data.
An AI system may need to understand an image and answer a question about it, or combine text and visual information to complete a task.
Attention-based architectures provide a useful way to model these relationships.
5. Scalability
Another major reason Transformers became popular is their ability to scale.
Their parallel processing approach works well with modern GPUs and other AI accelerators during training. This has made it possible to train models with billions of parameters and large amounts of data.
Scaling alone does not guarantee a better model, but it has played an important role in the development of modern AI.
6. Transfer Learning
Transformers can first be trained on broad datasets and later adapted to more specific tasks.
This approach means developers do not always need to train a complete model from scratch for every application.
A pretrained model can instead be fine-tuned or otherwise adapted for a particular use case.
7. Future AI Development
Transformer research is still evolving. Current work focuses on areas such as making attention more efficient, reducing memory requirements, handling longer contexts and improving model performance with fewer computational resources.
The architecture may also continue to evolve as AI systems become more specialized and multimodal.
Conclusion
Transformer Architecture has changed how computers handle language and other types of data. Its use of attention helps models connect related information, while parallel processing makes training large models more practical.
From the original encoder-decoder design to models such as BERT, GPT, T5, and Vision Transformer, the architecture now supports many tasks. Learning its key parts, including embeddings, self-attention, encoders, and decoders, provides a useful foundation for understanding modern AI systems.
Ready to start your journey? Book a free consultation with upGrad today to find the best path for your career
Frequently Asked Questions
1. Is ChatGPT based on Transformer Architecture?
Yes, ChatGPT is built on Transformer-based language models. More specifically, GPT models use a decoder-only Transformer design that generates responses by predicting tokens from the available context. The Transformer itself was introduced years before ChatGPT and later became a foundation for modern large language models.
2. Who built Transformer Architecture?
Transformer Architecture was developed by eight researchers who worked at Google and introduced their work in the 2017 paper Attention Is All You Need. The authors were Ashish Vaswani, Noam Shazeer, Niki Parmar, Jakob Uszkoreit, Llion Jones, Aidan N. Gomez, Lukasz Kaiser, and Illia Polosukhin.
3. What was the original Transformer designed for?
The original Transformer was developed mainly for sequence-to-sequence tasks, with machine translation as its main experimental focus. The researchers tested it on English-to-German and English-to-French translation. The architecture was designed to replace recurrent processing with attention-based computation.
4. Who is considered the father of Transformer Architecture?
There is no single officially recognised “father” of Transformer Architecture because the original work was a collaborative effort by eight authors. Ashish Vaswani is often associated with the architecture because he was the first-listed author, but the paper explicitly credited all eight contributors equally.
5. Who was the very first Transformer?
The first Transformer was the model described in the 2017 Attention Is All You Need paper. It used an encoder-decoder structure based entirely on attention mechanisms and was evaluated primarily on machine translation. It was not a chatbot or large language model like the systems commonly associated with Transformers today.
6. What are the different types of Transformer architectures?
Transformer models are commonly grouped into encoder-only, decoder-only, and encoder-decoder designs. These categories describe which major parts of the original architecture a model uses. They serve different purposes, ranging from language understanding to text generation and tasks that convert one sequence into another.
7. What are four types of Transformers?
There is no universally accepted list of exactly four Transformer types. Common classifications include encoder-only, decoder-only, and encoder-decoder models. Some discussions separately identify specialised architectures, such as vision or multimodal Transformers, based on the type of data they process rather than their core encoder-decoder structure.
8. Was the Transformer the first attention-based neural network?
No. Attention mechanisms existed before the Transformer. Earlier sequence models, particularly encoder-decoder systems for machine translation, already used attention to connect input and output information. The major change in 2017 was using attention as the central mechanism while removing recurrence and convolution from the proposed architecture.
9. What came before Transformer Architecture?
No. Attention mechanisms existed before the Transformer. Earlier sequence models, particularly encoder-decoder systems for machine translation, already used attention to connect input and output information. The major change in 2017 was using attention as the central mechanism while removing recurrence and convolution from the proposed architecture.
10. Why did Transformer Architecture become popular so quickly?
Its ability to process sequences more efficiently during training was a major factor. The original research showed strong machine-translation results while also making the model more parallelisable than recurrent approaches. Later developments such as pretrained Transformer models and large-scale training pushed the architecture into mainstream AI.
11. Is Transformer Architecture still used in modern AI?
Yes. Transformer-based designs remain widely used across language, vision, speech, and multimodal AI. They form the basis of many prominent language models and have also been adapted for tasks involving images and other data types. Research continues to explore ways to make Transformer systems faster and more efficient.
711 articles published
Sriram K is a Senior SEO Executive with a B.Tech in Information Technology from Dr. M.G.R. Educational and Research Institute, Chennai. With over a decade of experience in digital marketing, he specia...
Speak with AI & ML expert
By submitting, I accept the T&C and
Privacy Policy
